Description
Worldwide Electric 1.5 HP 3 Phase Electric Motor PEWWE1.5-18-145T
1.5 horsepower, 3 phase premium efficiency severe duty electric motor with a rigid base. Worldwide Electric designs and manufactures motors with quality and reliability in mind. This motor features Class F insulation, fan cooling, a 1.25 service factor (1.00 at 50Hz), and is a premium efficiency severe duty motor. Designed for 60Hz, features a TEFC / IP55 enclosure, and is a 145T frame.
Specifications:
• 1.5 Horsepower
• 3 Phase
• TEFC / IP55 Fully Enclosed
• 145T Frame
• Service Factor 1.25
• Class F Insulation
• 54.65 LBS
• 230/460 Volt
• 1755 RPM
• Fan Cooled
• Worldwide Electric Brand
• Keyed 7/8″ Diameter Shaft
• Current: AC
• Full Load Amps: 4.45/2.22 (Usable on 208V network at 4.92 amps)
• 60 HZ
• Shaft Material: 1045 Carbon Steel
• NEMA Design B
• Max Temp: 40 Degrees C
